Saf-D-Grid Power Cords

SAF-D-GRID® Power Cables AC / DC

These power cords connect devices carrying AC or DC currents up to 30A and 600V in the footprint of an IEC 620 C13/C14 and is the only connector system that is UL rated for disconnects. UL Rated to 400V and 30A.

  • Meets International safety requirements for hazardous, low voltage applications including UL 950 and IEC 60950
  • Allows for greater density of power by letting up to 600V DC and 40A or AC in the same space of IEC 320 C13/14 systems that have limits of 10A to 250 VAC
  • Saf-D-Grid® 400V targets DC applications but is also rated for AC current with a single keying configuration
  • Saf-D-Grid® 300V targets AC applications and is rated for DC with multiple mechanical keys



Shop SAF-D-GRID® Power Cords

First Mate, Last Break Ground Contact - Provides the safety of an earthing path before engagement of the power contacts.

Integral Latch - Connectors cannot be accidentally unmated, preventing unwanted power loss to critical equipment.

Hot Plug Rated - The connectors are rated for current interruption for both electronic (capacitive) and electrical (resistive) loads.

Touch Safe / Shock Protection - Minimizes the risk of personal contact with a hazardous voltage. Passes UL & IEC finger probe (plug & receptacle) and 3mm probe tests (receptacle).

Arcing Protection - Housings contain the arc if connectors are mated or unmated while under load minimizing risk to personnel.



FREQUENTLY ASKED QUESTIONS ABOUT SAF D GRID POWER CORDS

What is SAF D grid?
Anderson Power states that thes power cords build on the proven contact technology used in SB and Powerpole� connectors by offering features required in 380-400VDC power distribution systems. Saf-D-Grid connector systems created as a safe appliance power connector for server, telecommunication, and other devices up to 600 VDC.

Are Saf-D-Grid Power Cords compatible with the IEC 320C13 and C14 connection systems?
YES!

Are Saf-D-Grid Power Cords Powerful?
YES! It is the only connector system so sized that is UL rated for current interrupt of up to 400 VDC and 30 amp load. Saf-D-Grid also enables greater power density by allowing up to 30A and 600V (disconnect) DC or AC within the same space of the IEC320 C13 & C14 system that is typically limited to 10A and 250 VAC. This allows the use of Saf-D-Grid in AC systems that require more power by increasing the wattage capability within the existing connector space.



"I use these power cords religiously in all of my installations. Very reliable and high quality.
- Fred A - DanC IT
